Home Products Optical Transceiver SFP 1.25G SFP 1550nm 120km TRANSCEIVER
1.25G SFP 1550nm 120km TRANSCEIVER

1.25G SFP 1550nm 120km TRANSCEIVER

  • Product Item:TDS-24D2-55C
  • DATA RATE:1.25G
  • WAVE LENGTH:1550nm
  • DISTANCE:120KM
  • CONNECTOR:LC
  • 125g sfp  , 1g sfp  , 120km
    Inquiry Send Email

    Description

    1.25Gbps SFP Optical Transceiver, 120KM Reach

    Features

    Data-rate of 1.25Gbps operation

    1550nm DFB laser and APD photodetector for 120KM transmission

    Compliant with SFP MSA and SFF-8472 with duplex LC receptacle

    Digital Diagnostic Monitoring:Internal Calibration or External Calibration

    Compatible with SONET OC-24-LR-1

    Compatible with RoHS

    +3.3V single power supply

    Operating case temperature:

    Standard : 0 to +70°C

    Extended : -20 to +85°C

    Industrial : -40 to +85°


    Applications

    Gigabit Ethernet

    Fiber Channel

    Switch to Switch interface

    Switched backplane applications

    Router/Server interface

    Other optical transmission systems


    Description

    The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 110KM transmission distance with SMF.

    The transceiver consists of three sections: a DFB laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

    The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
