Home Products Optical Transceiver 25G SFP28 25G SFP28 LR 1310NM 10KM TRANSCEIVER
25G SFP28 LR 1310NM 10KM TRANSCEIVER

25G SFP28 LR 1310NM 10KM TRANSCEIVER

  • DATA RATE:25G
  • WAVE LENGTH:1310nm
  • DISTANCE:10KM
  • CONNECTOR: LC
  • 25G-SFP28-LR  , SM25G-LR  , SFP-1025G-LR-S  , SFP-25G-LR  , SFP-25G-LR-S  , SFP-25G-LR-DE  , JNP-SFP-25G-LR  , FTLF1436P3BCL  , MMA2L20-AR  , 10504
    Inquiry Send Email

    Description

    25Gbps 1310nm SFP28 Transceiver

    Features

    Ø Hot-pluggable SFP28 form factor

    Ø Supports 25Gbps data rate

    Ø Maximum link length of 10km

    Ø 1310nm DFB laser and PIN photo-detector

    Ø Internal CDR on both Transmitter and Receiver channel

    Ø Duplex LC receptacle

    Ø Single 3.3V power supply

    Ø Power dissipation < 1.5W

    Ø Digital diagnostics functions are available via the I2C interface

    Ø RoHS-6 compliant

    Ø Commercial case temperature range: 0°C to 70°C


    Applications Applications

    Ø 25GBASE-LR Ethernet


    Product description

    The Telelinc SFP28 transceiver is a single-Channel, Pluggable, Fiber-Optic SFP28 for 25 Gigabit Ethernet and Infiniband EDR Applications. It is a high performance module for short-range data communication and interconnect applications which operate at 25.78125 Gbps up to 10km. This module is designed to operate over single mode fiber systems using a nominal wavelength of 1310nm. The electrical interface uses a 20 contact edge type connector. The optical interface uses duplex LC receptacle. This module incorporates  proven circuit and technology to provide reliable long life, high performance, and consistent service.
